ATLAS COPCO (2436 x 1453)

Oil-Sealed Rotary Screw Vacuum Pumps

สอบถามรายละเอียดสินค้า หรือ ขอแคตตาล็อกสินค้า
Further detail of products required, pls feel free to contact us.


GHS 1200-4800: Oil-sealed rotary screw vacuum pumps,
1126-4778 m³/h, 662-2814 cfm

Oil-Sealed Rotary Screw Vacuum Pumps

Production Information :
Atlas Copco’s oil-sealed rotary screw vacuum pumps bring reliable, efficient rough vacuum to the general industry. The GHS 1200-4800 combines a robust oil-sealed rotary screw technology with Atlas Copco’s advanced screw element design.

Providing up to 4778 m3/h of vacuum pumping performance across six models, the GHS series is ideal for critical applications in printing, electronics, plastics, packaging, woodworking, bottling, canning and similar exacting industries.


Features and Benefits :

Robust Technology
The GHS 1200-4800 combine a technologically advanced screw design with robust and highly regarded oil-sealed rotary technology to produce a state-of-the-art, market-leading product.

High Reliability
In the GHS 1200-4800 range of vacuum pumps, industry-leading screw technology meets many years of vacuum know-how. Add a conservative approach to machine speed and you have all the benefits of Atlas Copco’s screw element, including inherent reliability, optimal efficiency and life cycle costs.

Outstanding Efficiency & Ease of Use
GHS rotary screw vacuum pumps outperform many other vacuum technologies in their operating pressure range. They are available ready to use, with all the options you need, and supported by the best know-how.



Slow Rotor Speed
• Ensuring that GHS 1200-4800 vacuum pumps are quiet – from 82 dB(A) – so they can be located alongside your machine in areas where people work.
• Guaranteeing high reliability and extreme durability.

Lift-out panels
Eliminating the need for swing-out doors, saving valuable space.

Innovative porting
• Optimizing performance when cycling from atmospheric pressure to the operating vacuum level.
• Preventing internal and efficiency sapping back-pressures during operation close to atmospheric pressure. The result is fast response to process changes.

Sound-Insulated Canopy
• Reduced sound levels.
• Enhancing the appearance of the vacuum pump.

Modulating Valve Fitted Directly to Pump Inlet
• Allowing delivered performance to be matched to actual demand.
• Minimizing fluctuations in system vacuum level.
• Reducing wear and maintenance, as a result of fewer stops/starts.

Adjustable Oil Thermostat
• Preventing condensed water vapor from contaminating the oil reservoir, even in demanding conditions.
• Consistent and continuous performance during humid duties with minimal impact on component lifetime within the oil circuit.

Generously Matched Motors
GHS 1200-4800 vacuum pumps are durable, highly reliable and fitted with generously rated motors making them last a lifetime.

Highly Efficient Oil Mist Separators
• Easily replaceable cartridge type elements sized to minimize back-pressure and optimizing the delivered performance.
• Ensuring long operating life with a minimum number of service interventions.
• Allowing operation close to atmospheric pressure, without the consequences often found when excessive optimization takes place.


GHS 350-1900 VSD+: Oil-sealed rotary screw vacuum pumps


Production Information :
Our new innovative and intelligent vacuum pump – the GHS VSD+ range of screw vacuum pumps with capacities up to 1900 m³/h – representing a real leap forward in the vacuum industry.

Features and Benefits :
The GHS VSD+ Series is a new range of highly efficient, intelligent vacuum pumps with Variable Speed Drive (VSD) from Atlas Copco. Based on the well-known and durable plug-and-play design principles of Atlas Copco compressors, these vacuum pumps have been designed by vacuum engineers to deliver peak performance at operating pressures commonly found in industrial applications. The GHS VSD+ series offer:
• Energy savings of around 50% A state-of-the-art technology, variable speed drive (VSD) and innovative motor design combine to produce a leap forward in efficiency to dramatically reduce lifecycle costs
• Significantly better performance against benchmarked oil-sealed and dry vane vacuum pump
• Quiet operation – Noise levels are around half that of comparable technologies.
• Sustainable productivity due to built-in efficiency. Conforms to energy management and environmental commitments according to ISO 50001/14001.
• Reduced environmental impact due to ultra-high oil retention at all operating pressures – from ultimate pressure to atmospheric pressure.
